Canon IPF770 A0 36" Colour CAD Printer

Canon IPF770 A0 36" Colour CAD Printer

Exceptional quality and accuracy
Canon’s 5-colour dye-and-pigment ink system produces the sharpest, thinnest lines. With an accuracy of +/- 0.1% and a minimum line width of 0.02mm, precision is guaranteed. Get more vibrant colours on CAD and GIS drawings, and better quality red text or images for posters and POS, with the iPF770’s reformulated magenta ink, which covers a broader spectrum than ever.

Ready for the cloud
Boost productivity and streamline printing workflows with imagePROGRAF Direct Print & Share, which lets you print a host of file types without needing an application. As well as PosterArtist integration, the solution allows you to upload and download files for immediate sharing, with easy access even from mobile devices. Printing from an iPad application is also supported.

Economical and efficient
Manage printing costs more easily with the built-in Status Monitor. The Status Monitor’s accounting function collects print job logs and automatically calculates costs per job or time period. An economy mode can be selected which uses less ink: ideal when printing draft documents.

Streamlined design
Make better use of your space with the Canon iPF770’s streamlined 36” body, which is high on features, but low on footprint. Its space-saving dimensions make it perfect for businesses who want high-productivity without the bulk.

Built for demanding workflows
The iPF770 is compatible with HP-GL/2 and HP-RTL, and includes the ability to set palette and pen settings for CAD workflows. Bundled software includes an Optimised Driver for AutoCAD, and a plug-in for Microsoft Office that lets you print directly from Word, Excel or PowerPoint.
Printer Type 5 Colour - 36"/914.4mm
Print Technology Canon Bubblejet on Demand 6 colours integrated type (6 chips per print head x 1 print head)
Number of Nozzles Total: 15,360 MBK: 5,120 nozzles
C, M, Y, BK: 2,560 nozzles each colour
Print Resolution 2,400 x 1,200 dpi
Nozzle Pitch 1,200 x 2 includes Non-firing nozzle detection and compensation system
Guaranteed Minimum Line Width 0.02 mm
Line Accuracy ±0.1 % or less
Ink Droplet Size 4 Picoliter per colour
Ink Capacity Bundled starter ink: 90 ml
Sales ink: 130 ml
Ink Type Dye/Pigment Reactive Ink
Dye: Cyan, Magenta, Yellow, Black
Pigment: 2 x Matte Black
OS Compatability Windows 32 bit – XP, Vista, 7, 8, 8.1, Server 2003/2003R2, Server 2008
Windows 64 bit – Vista, 7, 8, 8.1, Server 2003/2003R2, Server 2008/2008R2, Server 2012/2012R2
Mac: OSX – 10.6.8 - 10.10.x
Printer Languages GARO (Graphic Arts language with Raster Operations), HP-GL/2, HP RTL
Standard Interfaces USB 2.0 High-Speed
Ethernet 10/100/1000 Base-T/TX
PRINTING PAGE SIZE/PRINT SPEED

A0 Size, Plain Paper 0:48 min (Fast Economy Mode)
0:48 min (Fast Mode)
1:15 min (Standard Mode)
A0 Size, Coated Paper 1:15 min (Fast Mode)
2:24 min (Standard Mode)
3:50 min (High Quality Mode)
MEMORY

Buffer RAM 256Mb
Hard Drive N/A
PAPER HANDLING

Media Width Roll paper: 254 - 914.4mm
Cut sheet: 203.2 - 914.4mm
Media Thickness Roll Unit: 0.07 - 0.8mm
Top Loading Manual Feed: 0.07 - 0.8mm
Front Loading Manual Feed: 0.5 - 1.5mm
Minimum Printable Length Roll: 203.2mm
Cut Sheet: 279.4mm
Maximum Printable Length 18m (varies according to the OS and application)
Maximum Media Roll Diameter 150.0 mm
Paper Feed Method Roll Feed: One Roll, top loading, front output
Top Loading Manual Feed: One sheet, front output
Front Loading Manual Feed: One sheet, front output
Media Feed Capacity N/A
Borderless Printing Width (Roll Only) 10" (254 mm), B4 (257 mm), A3 (297 mm), Banner (300 mm), 14" (356 mm), A2 (420 mm), A2+/17" (432 mm), B2 (515 mm), A1 (594 mm), 24" (610 mm), B1 (728 mm), A0 (841 mm), 36" (914 mm)
DIMENSIONS AND WEIGHT

Physical Dimensions and Weight Main unit with a printer stand and basket open: 1304 (W) x 887 (D) x 1062 (H) mm
Main Unit with basket in extended position for flatbed stacking: 1304 (W) x 1100 (D) x 1062 (H) mm
Main Unit with Stand Weight: 64.6kg (ST-34, roll holder included, no inks, no print heads)
Software Included Canon Printer Driver, Status Monitor/Print Monitor, Printer Driver ExtraKit – Free Layout and iR enlargement Copy, Printer Driver Optimization Module for AutoCAD, Media Configuration Tool, PosterArtist Lite (PC only), Print Plug-in for Microsoft® Office (PC only), Direct Print & Share, Custom Installer Creation Tool
POWER AND OPERATING REQUIREMENTS

Power Supply AC 100 - 240 V (50-60 Hz)
Power Consumption Operation: 140W or less
Power off Standby: 0.5 W or less
Sleep mode Power Consumption: 5W or less
Time to enter sleep mode: Approx. 5 Minutes
Operating Environment 15 - 30°C, 10 - 80 % (Condensation free)
Noise Level (Approx.) Operation: approx. 46 dB
Standby: 35 dB or less
Accoustic Power: 6.4 Bels
Based on ISO 7779
Filters
ApplicationCAD Printing
Printer SizeA0

Printer with Stand


1 x print head, 1 x set of starter ink tanks - (C, M, Y, BK, 2 x MBK) 90ml each, 3 inch core adapters, Set up guide, Basic guide, Manual CD-ROM, User software CD-ROM (Mac & Win), Carrying caution leaflet, A2 calibration sheet, Safety/Standard Environment leaflet, Media sample - sheets, PosterArtist Lite leaflet, PosterArtist Lite software CD-ROM, EU/UK Power Cord.


Software Included


Canon Printer Driver, Status Monitor/Print Monitor, Printer Driver ExtraKit – Free Layout and iR enlargement Copy, Printer Driver Optimization Module for AutoCAD, Media Configuration Tool, PosterArtist Lite (PC only), Print Plug-in for Microsoft® Office (PC only), Direct Print & Share, Custom Installer Creation Tool

1 Year



Write a review

Note: HTML is not translated!
    Bad           Good

  • Views: 4794
  • Brand: Canon
  • Product Code: iPF770
  • Pack Qty: 1
  • Individual Price : £0.00
  • Availability: End of Line
  • £0.00 Ex VAT
  • Inc VAT £0.00

Product Description

Canon imagePROGRAF iPF770

Designed for the CAD, GIS, poster, and in-house print market

The imagePROGRAF iPF770 is a 36”/A0 printer, delivering class leading productivity, exceptional quality, accuracy and an advanced set of features to ensure an excellent return on investment.

This streamlined Canon printer has 5 colours and with a print speed of 48 seconds for a high quality A0 CAD drawing. Making it prefect for layouts, plans, maps and presentations and posters.
