HP DesignJet Z9+ 24" 9 Ink Postscript Printer using fewer inks for fast, secure quality prints with a built in Spectrophotometer.
.
PRECISE — Clearly distinguish subtle details
• Read details more clearly and see highcontrast color with new high-definition HP printheads.
• No need for light inks with HP’s dual drop technology.
• Get smooth gradients, even for challenging color combinations, with HP Pixel Control.
• Work with water- and fade-resistant prints, indoors and out, with HP Vivid Photo Inks
FAST — Work without delays
• Handle even the most complex files with powerful processing architecture and the Adobe PDF Print Engine.3
• Cut maps to different sizes in fewer steps with the first printer including an integrated vertical trimmer.1
• Print up to 20% faster4 with 2400 nozzleper-inch, high-definition HP printheads.
• Spend less time on media changes and adjustments with dual roll support and automatic roll switching.1
SECURE — Protect your work and your information
• Protect printers/data from unauthorized access with HP Secure Boot, whitelisting, and encrypted hard disk.
• Protect documents, preserve
confidentiality with authentication solutions like PIN printing, card readers.5
• Secure your printers with HP JetAdvantage Security Manager; manage your fleet remotely with HP Web Jetadmin.
Trade-in included
More quality with fewer inks. Deliver professional photo and high-definition
prints and save time with the first integrated vertical trimmer.1 Protect your work and information with industry-leading security. Get incredible results without compromising. You can have it all.
Designed to deliver professional photo quality with fewer inks at high speeds, the HP DesignJet Z9+ PostScript® Printer Series prints 2.5 times faster4 without sacrificing quality. Its integrated
vertical trimmer cuts post-processing time by up to 20%.2 And we help streamline your workflow with
software solutions like HP Applications Center.3
Technology innovations
Innovative HP technologies work in tandem to provide professional photo quality—without speed tradeoffs and with fewer inks.
Original HP Vivid Photo Inks are optimized to deliver amazing, professional quality prints on photo and specialty papers, and are designed to maximize the life of high-definition HP printheads. Chromatic red, blue, and green inks (RGB) enable an expanded color gamut with true neutral gray.5 HP Vivid Photo Inks provide water- and fade-resistant prints.6
New HP 746 Printheads with true 2400 nozzle-per-inch high-definition nozzle architecture (HDNA), provide twice the nozzle
density of previous HP DesignJet Z-series printheads. Using dual drop technology, high-definition HP printheads produce a combination of large drop sizes for robust area fills at fast speeds, while small drop sizes reduce visible grain—eliminating the
need for light colored inks.
Managing all of this with a completely new approach, HP DesignJet Z9+ and Z6 series printers use HP Pixel Control to produce sharp details and smooth gradients, even for challenging color combinations.
Security at the forefront Protect your work and your information with industry-leading security. HP is working in the background to protect your device, data, and documents. Limit unauthorized access to your device and your data with HP Secure Boot, whitelisting, and a selfencrypted hard disk. Authentication solutions like PIN printing and integrated pull printing 8 help preserve confidentiality. While
HP JetAdvantage Security Manager simplifies security management across your printing environment.
1 Vertical trimmer and dual rolls included with the HP DesignJet Z6dr 44-in
PostScript® Printer with V-Trimmer only.
2 Vertical trimmer and dual rolls included with the HP DesignJet Z9+
dr 44-in PostScript® Printer with V-Trimmer only. Up to 20% reduction in
post-processing labor time based on internal HP testing compared to HP DesignJet Z9+dr series printers without built-in vertical trimmer.
3 Applications Center: Requires an HP Applications Center account,
Internet connection, and connected Internet-capable device. For more information, see hpapplicationscenter.com.
4 Based on internal HP testing. Up to 2.5 times faster printing compared to
the HP DesignJet Z3200 Photo Printer series. May vary depending on print
mode and media type.
5 Chromatic blue, chromatic green, gray, and optional gloss enhancer available with the HP DesignJet Z9+ PostScript® Printer series only. Optional gloss enhancer upgrade available second half 2018.
6 Performance may vary based on writing system differences. Print permanence estimates by HP Image Permanence Lab based on the same
formulation of HP Vivid Photo Inks used with the HP DesignJet Z6200 Photo Production Printer, using 6 inks. Water resistance performance
varies based on printer and print profile. Water resistance testing by HP Image Permanence Lab on a range of HP media and follows ISO 18935 method. Display permanence rating for interior displays/away from direct
sunlight by HP Image Permanence Lab on a range of HP media. For more
information, see HPLFMedia.com/printpermanence.
7 Based on internal HP testing, comparing to HP DesignJet Z9+ series printers without gloss enhancer. HP Gloss Enhancer can be used on photo paper, with the exception of matte-finish papers. Optional upgrade
available second half 2018.
8 HP DesignJet Z9+ and Z6 PostScript® Printer series products are fully compatible with Celiveo PIN and pull printing solutions.
Detailed Specifications
Acoustic power emissions6.0-6.3 B(A)
Acoustic power emissions (sleep)<3.4 B(A)
Acoustic power emissions (standby)5.1 B(A)
Acoustic pressure emissions42-45 dB(A)
Acoustic pressure emissions (sleep)<16 dB(A)
Acoustic pressure emissions (standby)33 dB(A)
Additional information about HPhttp://www.hp.com
Additional information about HP in the countrieshttp://www.hp.com/uk
Code nameJaguar 9
Color accuracyMedian < 1.6 dE2000, 95% of colours < 2.8 dE2000[5]
Color accuracy noteICC absolute colorimetric accuracy on HP Premium Instant-dry Satin Photo Paper with HP Vivid Photo Inks.
Color Stability< 1 dE2000 in less than 5 minutes[6]
Color Stability NoteWith HP Premium Instant-dry Satin Photo Paper with HP Vivid Photo Inks.
Color(s) of printing suppliesCyan, magenta, yellow, matte black, photo black, chromatic red, chromatic green, chromatic blue, grey
Connectivity, standard10/100/1000Base-T Ethernet (802.3, 802.3u, 802.3ab); USB Type-A host port
Copyright notice© Copyright 2018 HP Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
Datasheet publication number4AA7-2603
Electromagnetic compatibilityCompliant with Class B requirements, including: EU (EMC Directive), South Africa (SABS)
Energy efficiencyENERGY STAR® qualified
ENERGY STAR® certifiedYes
Environmental certificationENERGY STAR; ErP; WEEE; RoHS (EU); REACH; EPEAT Silver
Finished output handlingSingle-roll: roll feed, top sheet feed, rear sheet feed for rigid media, media output bin, automatic horizontal cutter; Dual-roll: two automatic roll feeds, smart roll-switching, top sheet feed, media output bin, automatic horizontal cutter and vertical trimmer (cuts all HP Z-series printer-qualified media, including most canvas)
FunctionsPrint
Guaranteed minimum line width0.0031 in (ISO/IEC 13660:2001(E))
Guaranteed minimum line width0.08 mm (ISO/IEC 13660:2001(E))
Guaranteed minimum line width footnoteMeasured on HP Matte Film.
Guaranteed minimum line width footnoteMeasured on HP Matte Film.
Image legal disclaimerProduct image may differ from actual product
Ink drop7/3 pl dual-drop weight (M, C, PK, CB, G); 6 pl single-drop weight (Y, CR, MK, CG)
Ink typesPigment-based
Internal Storage500 GB self-encrypting
Line accuracy±0.1%
Line accuracy note±0.1% of the specified vector length or ±0.2 mm (whichever greater) at 23ºC (73ºF), 50-60% relative humidity, on A0/E HP Matte Film in Best or Normal mode with HP Vivid Photo Inks.
Maximum optical density (black)4 L* min/2.5 D[6]
Maximum optical density footnote (black)With HP Premium Instant-dry Satin Photo Paper with HP Vivid Photo Inks.
Media sizes standard (metric rolls)24-in: 279 to 610-mm; 44-in: 279 to 1118-mm
Media sizes standard (sheets, rolls)24-in: 11 to 24-in; 44-in: 11 to 44-in
Media sizes supported24-in: A, B, C, D; 44-in: A, B, C, D, E
Media sizes supported24-in: A4, A3, A2, A1; 44-in: A4, A3, A2, A1, A0
Media sizes, custom24-in: 210 x 279 to 610 x 1676 mm; 44-in: 210 x 279 to 1118 x 1676 mm
Media sizes, custom24-in: 8.3 x 11 to 24 x 66 in; 44-in: 8.3 x 11 to 44 x 66 in
Media thicknessUp to 0.8 mm
Media thicknessUp to 31.5 mil
Media typesPhotographic, fine art printing material, self-adhesive, banner and sign, bond and coated, backlit
Media weight, recommended80 to 500 g/m²
Memory128 GB (virtual)[4]
Memory NoteBased on 4 GB RAM.
Minimum dimensions (W x D x H)24-in: 1293 x 695 x 998 mm; 44-in: 1802 x 695 x 998 mm
Minimum dimensions (W x D x H)24-in: 50.9 x 27.4 x 39.3 in; 44-in: 71 x 27.4 x 39.3 in
Mobile printing capabilityDirect print for mobile apps for iOS, Android and Chrome OS; Email printing with HP ePrint and HP Smart app for iOS and Android.
Network readyStandard
Non-printable area (cut-sheet)0.2 x 0.67 x 0.2 x 0.2 in
Non-printable area (cut-sheet)5 x 17 x 5 x 5 mm
Non-printable area (roll media)0.2 x 0.2 x 0.2 x 0.2 in (borderless on select media[2], and on all media when using V-Trimmer[3])
Non-printable area (roll media)5 x 5 x 5 x 5 mm (borderless on select media[2], and on all media when using V-Trimmer[3])
Number of print cartridges9 (cyan, magenta, yellow, matte black, photo black, chromatic red, chromatic green, chromatic blue, grey), optional gloss enhancer
Operating humidity range20 to 80% RH
Operating temperature range41 to 104ºF
Operating temperature range5 to 40ºC
Package dimensions (W x D x H)24-in: 1440 x 766 x 718 mm; 44-in: 1950 x 766 x 718 mm
Package dimensions (W x D x H)24-in: 56.7 x 30.2 x 28.3 in; 44-in: 76.8 x 30.2 x 28.3 in
Package weight102-137 kg
Package weight225-302 lb
PowerInput voltage (auto ranging): 100-240 V (±10%), 50/60 Hz (±3 Hz), 2 A max
Power consumption< 100 W (printing); < 32 W (ready); < 0.3 W (sleep) (< 6.5 W with embedded Digital Front End); 0.1 W (off)
Print cartridge volume deliveredHP 746 Ink Cartridge: cyan, magenta, chromatic red, yellow, matte black, photo black (300 ml); HP 747 Ink Cartridge: chromatic green, chromatic blue, grey (300 ml)
Print head nozzles2112 per colour
Print heads5 universal printheads (valid for all colours)
Print languagesAdobe PostScript 3, Adobe PDF 1.7, TIFF, JPEG, CALS G4, HP-GL/2, HP-RTL
Print quality color (best)Up to 2400 x 1200 optimised dpi
Print repeatabilityAverage < 0.5 dE2000, 95% of colours < 1.4 dE2000[6]
Print repeatability noteWith HP Premium Instant-dry Satin Photo Paper with HP Vivid Photo Inks.
Print speed73.9 m²/hr[1]
Print speed795 ft²/hr[1]
Print speed color image (best, glossy paper)4.5 m²/hr[1]
Print speed color image (best, glossy paper)48 ft²/hr[1]
Print speed color image (normal, coated paper)24.6 m²/hr[1]
Print speed color image (normal, coated paper)265 ft²/hr[1]
Print speed footnote (metric)Maximum rate of output for colour image 100% colour coverage. Printed in Economode, on HP Bright White Inkjet Paper (bond), maximum roll size, with Original HP Vivid Photo Inks. Measured on a 44-in printer.
Print speed note (imperial)Maximum rate of output for colour image 100% colour coverage. Printed in Economode, on HP Bright White Inkjet Paper (bond), maximum roll size, with Original HP Vivid Photo Inks. Measured on a 44-in printer.
Print technologyHP Thermal Inkjet
Print TechnologyInk
Print time color image ISO N5 (best, metric A1 glossy paper)7.2 min/page[2]
Print time color image ISO N5 (normal metric A1 coated paper)1.2 min/page[2]
Printer drivers includedRaster and PostScript drivers for Windows and macOS; PDF driver for Windows
Recommended mediaQ6581A HP Universal Instant-dry Satin Photo Paper (FSC® certified)[9] (Recyclable)[10] 1067 mm x 30.5 m (42 in x 100 ft);E4J57A HP Artist Matte Canvas 1118 mm x 15.2 m (44 in x 50 ft);C6569C HP Heavyweight Coated Paper (FSC® certified)[9] (Recyclable)[10] 1067 mm x 30.5 m (42 in x 100 ft);CH025A HP Everyday Matte Polypropylene, 2 Pack (Recyclable)[10] 1067 mm x 30.5 m (42 in x 100 ft);CG460B HP Premium Matte Photo Paper (FSC® certified)[9] (Recyclable)[10] 914 mm x 30.5 m (36 in x 100 ft)
Roll external diameter135 mm
Roll external diameter5.3 in
SafetyEU (LVD and EN 60950-1 compliant); Russia, Belarus, Kazakhstan (EAC)
Security featuresHP Secure Boot, Whitelisting, Role Based Access Control, SNMPv3, HTTPS, Secure-IPP, IPsec/Firewall, Certificates management, 802.1X, TLS 1.0/1.1/1.2, HP Web Jetadmin compatible, HP JetAdvantage Security Manager compatible, Secure Disk erase (DoD 5220.22-M), Secure File erase, self-encrypted HDD, PIN printing
Software includedFree: HP Applications Center, HP Click, printer drivers, HP DesignJet Utility including HP Color Center, HP Partner Link Pay-per-use, HP PrintOS, HP Web JetAdmin; Pay: HP JetAdvantage Security Manager
Storage temperature range-13 to 131ºF
Storage temperature range-25 to 55ºC
Tech spec footnote[1] Maximum rate of output for colour image 100% colour coverage. Printed in Economode, on HP Bright White Inkjet Paper (bond), maximum roll size, with Original HP Vivid Photo Inks. Measured on a 44-in printer.
Tech spec footnote[10] Recyclable HP papers can be recycled through commonly available recycling programs, or according to region-specific practices, or can be returned through the HP Large Format Media take-back program. Recycling programs may not exist in your area. See http://www.HPLFMedia.com/hp/ecosolutions for details.
Tech spec footnote[2] Borderless printing available on photo, polypropylene, and backlit roll media.
Tech spec footnote[3] Except self-adhesive vinyls and non-cuttable medias.
Tech spec footnote[4] Based on 4 GB RAM.
Tech spec footnote[5] Not included in the box for 24-in models.
Tech spec footnote[6] With HP Premium Instant-dry Satin Photo Paper with HP Vivid Photo Inks.
Tech spec footnote[7] Mechanical printing time with Original HP Vivid Photo Inks. Measured on a 44-in printer.
Tech spec footnote[8] ICC absolute colour metric accuracy on HP Premium Instant-dry Satin Photo Paper with HP Vivid Photo Inks.
Tech spec footnote[9] BMG trademark license code FSC®-C115319, see http://www.fsc.org. HP trademark license code FSC®-C017543, see http://www.fsc.org. Not all FSC®-certified products are available in all regions.
Theoretical minimum line width0.0008 in (PDF addressable at 1200 dpi)
Theoretical minimum line width0.02 mm (PDF addressable at 1200 dpi)
WarrantyOne-year limited hardware warranty
Web address for additional informationhttp://www.hp.com/go/designjetZ9
Weight 159-216 lb
Weigh t72-98 kg
Filters | |
Application | Photo Printing |
No. of Printer Inks | 9 Ink System |
Printer Options | Postscript |
Printer Size | A1 |
HP DesignJet Z9+ PostScript Printer
Printheads
Introductory ink cartridges 69ml per colour
Printer stand and media bin
Spindle
7.62 cm (3 in) core adapter[6]
Quick reference guide
Setup poster
Power cord
Software included
Free: HP Applications Center
HP Click
printer drivers
HP DesignJet Utility including HP Color Center
HP Partner Link Pay-per-use
HP PrintOS
HP Web JetAdmin; Pay: HP JetAdvantage Security Manager
1 Year
Delivery Information
Prizma Graphics offers a nationwide delivery service. Orders received by 3pm will be shipped the same day.
We hold huge stocks and we aim to deliver all out of stock items within 3 - 5 days
We deliver to the following towns by our own van and all other areas are sent out by national courier service.
Aylesbury | Chesham | High Wycombe | Princes Risborough | Wembley | |
Abingdon | Didcot | Hitchin | Reading | Welwyn Garden City | |
Amersham | Dunstable | Kidlington | Richmond | Windsor | |
Ascot | Eton | Kingston | St Albans | Witney | |
Banbury | Egham | Leatherhead | Slough | ||
Beaconsfield | Farnham | Leighton Buzzard | Stevenage | ||
Bedford | Farnborough | Luton | Thame | ||
Berkhamsted | Great Missendon | Maidenhead | Tring | ||
Bicester | Guildford | Marlow | Twickenham | ||
Bracknell | Hatfield | Milton Keynes | Uxbridge | ||
Brackley | Harrow | Newbury | Wallingford | ||
Buckingham | Henley | Oxford | Watford | ||
Camberley | Hemel Hempstead | Potters Bar | West London |
.
UK Mainland Standard Delivery 1 - 2 days £6.95
Next Day (Delivery Hours 9.00 - 17.00) £9.95 - Cut Off Time for Next Day Delivery is 3pm.
Next Day AM (Delivery Hours 9.00 - 12.00) £14.95 - Cut Off Time for Next Day AM is 3pm.
Saturday Delivery £30.00 - Cut Off Time is 3pm Friday,
Same Day Delivery is available - Please call our sales team on 01296 393700 To discuss your requirements.
Collection by Arrangement FREE
UK Channel Islands Standard Delivery (up to 15kg) £20.25
UK Isle of Man Standard Delivery (up to 15kg) £20.25
UK Isle of Wight Standard Delivery (up to 15kg) £15.75
UK Northern Ireland Standard Delivery (up to 15kg) £20.25
Ireland Standard Delivery (up to 15kg) £40.70
UK Scilly Isles Standard Delivery (up to 15kg) £20.25
UK Scottish Highlands Standard Delivery (up to 15kg) £15.75
UK Scottish Islands Standard Delivery (up to 10kg) £20.25
If your order is over the weight shown, we will contact you with any additional costs.
Standard delivery to these locations are normally 2 – 3 days.
Scottish Highlands Covers: AB36-38, AB55-56, FK17-21, IV1-39, IV52-54, IV6363, KW1-14, PA21-40, PH19-26, PH30-41 & PH49-50.
Scottish Islands Covers: HS1-9, IV40-51, IV55-56, KA27-28, KW15-17, PA20, PA41-49, PA60-78, PH42-44 & ZE1-3.
All prices exclude VAT.
Collection by Arrangement
We will contact you once the order has been placed with a convenient time to collect from our warehouse in Aylesbury, Bucks.
Orders outside UK
We are happy to accept orders for delivery outside the UK. However a additional delivery will be charged . Please call us on 01296 393700 and we will be happy to provide a quote for you.
Next day cut off times
Orders that require delivery next day or next day am need to be placed before these cut off times.
Monday, Cut off for next day delivery 2.30pm
Tuesday, Cut off for next day delivery 2.30pm
Wednesday, Cut off for next day delivery 2.30pm
Thursday, Cut off for next day delivery 2.30pm
Friday, Cut off for next day delivery 2.30pm (next working day which is Monday)
Saturday, Closed
Sunday, Closed
