Canon imagePROGRAF Pro-1000 A2 17" Desktop 12 Colour Photo Printer Sheet Feed - 0608C026AA
Striking prints up to A2
Enjoy the ability to print striking, borderless images up to A2 without compromising quality. Take advantage of fast print speeds and colour accuracy: with a variety of media types supported – from gloss, matte, fine art papers and canvas – you’re guaranteed to get the look and feel you desire.
Improved light reflection and reduced bronzing
Canon's Chroma Optimizer ink technology helps to achieve uniform glossiness when printing on glossy paper. By being applied over the printed image Chroma Optimizer regulates the surface reflection to deliver natural colour reproduction in the finished print. This creates images with deep black density and prevents unwanted bronzing in your prints.
Superb Black and White Prints
You can produce fantastic black & white prints with neutral tones thanks to the LUCIA PRO ink system’s four dedicated monochrome inks – photo black, matt black, grey and photo grey.
Professional and functional design
The imagePROGRAF PRO-1000 printer inherits the red line from the EOS series – a symbol of exceptional quality. With a professional and functional design this desktop model is sure to inspire professional and amateur photographers alike. It features a rigid chassis to ensure accurate ink ejection and an additional manual feed tray lets you work with heavier paper types.
Increased efficiency for high volume use
Large capacity 80ml ink tanks reduce the need for frequent ink changes and a simple-to-replace maintenance cartridge increase efficiency for high volume print users. All 12 inks are easily loaded from the front of the printer and are housed behind a flip down cover.
Flexible settings and colour management
Canon’s Print Studio Pro plug-in features a new screen layout that makes it easier for you to adjust the printer, paper, layout and colour settings to help deliver the best quality prints. You can create favorite settings that you feel comfortable with and come back to them time and time again. Colour management is easier than ever, with a simple box to allow ICC profile selection, rendering intent and a brand new feature to enable soft proofing.
PRODUCT SPECIFICATION
Class
17"
Ink Type
12 Inks: MBK/PBK/C/M/Y/PC/PM/GY/PGY/R/B/CO
Maximum Print Resolution
Maximum Print Resolution¹
2,400 x 1,200 dpi
Printing Speed
Printing Speed¹
A2 (LU-101 colour): Approx. 3min 35s
A2 (PT-101 colour or mono): Approx. 6mins
Dimensions, Weight
Approx. 723 x 435 x 285 mm
Weight approx. 32.3kg (including print head and inks)
Power Supply
AC 100-240V(50-60Hz)
Power consumption (approx 37W)¹
Standby consumption (approx 2.5W)
Power off (approx 0.4W)
Operational Environment
Temperature: 5-35°C, Humidity: 10-90%RH (no dew condensation)¹
Acoustic Noise
approx. 41.0 dB(A) - Photo (4"x6")¹
approx. 40.8 Db(A) - Document (A4. B/W), Quiet Mode OFF²
approx. 40.4 Db(A) - Document (A4. B/W), Quiet Mode ON
Operation Panel Display
3.0" (320 x 240 TFT LCD), Key x 13, LED x 2
21 Languages Selectable: English/German/French/Turkish/Italian/Spanish/Portuguese/Dutch/Polish/Hungarian/Danish/Norwegian/Swedish/Finnish/Czech/Russian/Simplified Chinese/Traditional Chinese/Thai/Indonesian/Japanese
Memory
1GB
INTERFACE TYPE & SOFTWARE
Supported Operating Systems
Supported Operating Systems¹
Windows 32bit:
Windows Vista, Windows 7, Windows 8, Windows 8.1, Windows 10
Windows Server 2008
Windows 64bit:
Windows Vista , Windows 7, Windows 8, Windows 8.1, Windows 10
Windows Server 2008/2008R2, Windows Server 2012/2012R2
*Windows RT(Windows 8 ARM version) is not supported
Macintosh
OS10.7.5 - OS10.10.x
Supported Mobile Systems
iOS
Android
Interface
Hi Speed USB Type: Built-in
USB 2.0 High-Speed Full Speed (12 Mbit/sec), High Speed (480 Mbit/sec), Bulk transfer
Wireless LAN
Wi-Fi
IEEE802.11n
IEEE802.11g
IEEE802.11b
Please refer to the user manual for instructions on how to activate/deactivate the wireless LAN.
Ethernet
Type Built-in:
IEEE 802.3 10base-T
IEEE 802.3u 100base-TX
Auto-Negotiation
Smart device & Cloud apps
Canon PRINT app (iOS or Android)
Pro Gallery Print app (iPad only)
PIXMA Cloud Link
Apple AirPrint
Google Cloud Print
Camera direct
Wi-Fi Pictbridge
Software
Print Studio Pro, Quick Utility Toolbox
PRINT HEAD
Type
Canon Bubble-jet on Demand
Head Configuration
12 colors integrated type (4 colors chips x 3)
Nozzle Pitch
600dpi x 2
Nozzle per Chip
1,536 nozzles x 12 colors, includes Non-firing nozzle detection and compensation system
Droplet Size
Minimum 4pl
INK TANK
Model
LUCIA PRO Ink Tanks:
PFI-1000
MBK/ PBK/C/M/Y/PC/PM/GY/PGY/R/B/CO
Page yield (4x6" PT-101)
Page yield (4x6" PT-101)¹
Number of 10x15cm photos
Matte Black (MBK): 5490 photos*
Photo Black (PBK): 2205 photos*
Grey (GY): 1465 photos*
Photo Grey (PGY): 3165 photos*
Photo Cyan (PC): 5140 photos*
Cyan (C): 5025 photos*
Photo Magenta (PM): 3755 photos
Magenta (M): 5885 photos*
Yellow (Y): 3365 photos
Red (R): 5355 photos*
Blue (B): 4875 photos*
Chroma Optimizer (CO): 680 photos
* Estimated Supplemental Yield
Page yield (A2 PT-101)
Page yield (A2 PT-101)¹
Number of A2 colour photos
Matte Black (MBK): 1600 photos*
Photo Black (PBK): 256 photos*
Grey (GY): 106 photos*
Photo Grey (PGY): 270 photos*
Photo Cyan (PC): 600 photos*
Cyan (C): 675 photos*
Photo Magenta (PM): 374 photos*
Magenta (M): 965 photos*
Yellow (Y): 329 photos
Red (R): 935 photos*
Blue (B): 545 photos*
Chroma Optimizer (CO): 97 photos*
* Estimated Supplemental Yield
MEDIA HANDLING
Media Feeding
Rear tray/Manual feed slot
Media Type
Plain Paper,
Photo Paper Plus Glossy II,
Photo Paper Pro Platinum,
Photo Paper Pro Luster,
Photo Paper Plus Semi-gloss,
Photo Paper Pro Premium Matte,
Matte Photo Paper,
Other Fine Art, Canvas and Glossy Photo Papers
Media size
A5, A4, A3, A3+, A2, B5, B4, B3,
4x6", 5x7", 8x10", 10x12", 14x17", 17x22", LTR, LGL, LDR
Media Thickness
Rear tray: Plain paper 64-105g/m2, Canon specialty paper Max. 300g/m2,
Rear tray thickness: 0.1-0.3mm
Manual feed slot: Canon specialty paper Max. 400g/m2,
Manual feed thickness: 0.1-0.7mm
Media Width
Rear tray: 89-432mm,
Manual feed slot: 203.2-432mm
Minimal Printable Paper Length
Rear tray: 127mm
Manual feed slot: 254mm
Maximum Printable Paper Length
647.7mm
Margins (Top, Bottoms, Sides)
Recommended - Top margin: 57mm, Bottom margin: 55mm, Left/Right: 3.4mm
(LTR/LGL: Left margin 6.4mm, Right margin 6.3mm)
Printable area -Top margin 3mm, Bottom margin 5mm, Left/Right margin 3.4mm
(LTR/LGL: Left margin 6.4mm, Right margin 6.3mm)
Media Width for Borderless Printing
Media Width for Borderless Printing¹
A4, A3, A3+, A2, 4x6", 5x7", 8x10", 10x12", 14x17", 17x22", LTR
CONSUMABLES
Ink Tank
PFI-1000 MBK/PBK/C/M/Y/PC/PM/GY/PGY/R/B/CO (80ml)
Maintenance Cartridge
MC-20
Filters | |
Application | Photo & Fine Art Printing |
Ink Compatibility | Pigment |
Max Paper/Media Weight | 300gsm |
Memory | 1Gb |
No. of Printer Inks | 12 Ink System |
Printer Size | A2 |
Wireless | Yes |
Printer, set of inks, printhead, printer drivers and instructions
The Canon PRO-1000 is supplied with a 1 year manufacturer's warranty.
